| Maximum Speed | Forward≤22km/h;Reverse≤9km/h | Driving Range | 60-70km (Flat terrain, no load) |
| Grade Ability | 40% (≈21.8°) | Braking Distance | 2.5m |
| Turning Radius | ≤2.8m | Dimension | 2510×1220×1850(mm) |
| Wheelbase | 1650mm | Track | Front: 870mm;Rear: 985mm |
| Minimum gap | 114mm | Payload | 260kg (2persons) |
| Weight | 430kg(Battery included) | Charging time | 8-10hours(Discharge rate 80%) |
| Motor | KDS(ADC), Three-phase asynchronous AC, 48V/3kw |
| Battery | Trojan 6×8V/170AH or US 6x8V/170AH |
| Controller | Curtis1234, 48V |
| Dashboard | Battery Indicator |
| Accelerator | HXJS |
| Wire harness | Waterproof wire harness IP67 |
| Charger | 48V/25A, automatic power off, overload protection |
| Frame | High strength aluminum alloy chassis |
| Suspension | Front suspension:Macpherson independent suspension ,Rear suspension:Single leaf spring and telescopic hydraulic shock absorbers |
| Real axle | Complete rear axle, speed reducing ratio 16:1, Italian technology, Cast aluminum alloy gearbox housing |
| Steering | Bidirectional output gear rack steering machine |
| Brakes | Mechanical drum brake & Electromagnetic excitation brake & Electric parking . |
| Tire | Carlisle 18×8.5-8(4ply), ≤22PSI |
| Canopy | Injection, form in one piece, rain guide function |
| Body | Modified PP injection cover, automobile grade color registers coating |
| Windshield | PC shield |
| Seat | PU seat |
| Seat Direction | Same direction, one row，two seats |
| Light | LED headlight; taillight; brake light |
| Others | Rear view mirror, plastic basket, scoreboard kits, bunker rake position block and rear fender |
| Color | □ White □ Red □ Green |
| Optional Accessories | Part No. B420100 | □ Caddie stands |
| Part No. E030090 | □ Cooler box kit |
| Part No. 4063730 | □ Rain curtain |
