| Maximum Speed | Forward≤25km/h;Reverse≤9km/h | Driving Range | 80-90km (Flat terrain, no load) |
| Grade Ability | 15% (≈8.5°) | Braking Distance | 4m |
| Turning Radius | ≤5.5m | Dimension | 4350×1350×1950mm |
| Wheelbase | 3300mm | Track | Front: 880mm;Rear: 1000mm |
| Minimum Gap | 114mm | Payload | 880kg (11persons) |
| Weight | 705kg(Battery included) | Charging Time | 8-10 hours(Discharge rate 80%) |
| Motor | GREENMAN, Three-phase asynchronous, AC,48V/4kW |
| Battery | Trojan 8X6V/225AH or US 8X6V/232AH |
| Controller | Toyota,48M350,48V/350A |
| Dashboard | Battery Indicator |
| Accelerator | HXJS |
| Wire Harness | Waterproof wire harness IP67 |
| Charger | Automatic power off, overload protection |
| Frame | High strength carbon steel chassis |
| Suspension | Front suspension:Macpherson independent suspension; Rear suspension: multi-leaf spring and telescopic hydraulic shock absorber |
| Real Axle | Complete rear axle, speed reducing ratio 16:1, Italian technology, cast aluminum alloy gearbox housing |
| Steering | Bidirectional output gear rack steering machine |
| Brakes | Four-wheel hydraulic drum brake & Electromagnetic excitation brake & Electric parking |
| Tire | Front: 18×8.5-8(4ply); Rear: 18×8.0-10(6ply), Steel wheel hub |
| Canopy | Injection, form in one piece, rain guide function |
| Body | Modified PP injection cover, automobile grade color registers coating |
| Windshield | PC shield |
| Seat | PU Seat |
| Seat Direction | Same direction, 4 rows, first row for two seats and others each for 3 seats, total 11persons |
| Light | LED headlight; taillight; brake light; turn signals |
| Others | Backup buzzer, wing mirrors, rear view mirror, horn and rear bumper |
| Color | □ White □ Red □ Green |
| Optional Accessories | Part No.94.7101711 | Integrated panel kit ( speedometer,mileage ,battery indicator) |
